Coating Thickness Gauge for Iron and Non-Iron Metals

Coating Thickness Gauge for Iron and Non-Iron Metals
for non-destructive measurements of the coating thickness
suitable for non-magnetic coatings such as paint, enamel, chrome on ferrous metals and insulating coatings such as paint, anodized on non-ferrous metals
LCD display with 128 x 128 dot matrix
easy-to-understand menu navigation
different measurement modes like single and continuous measurements
probe modes like induction and eddy current
group modes like direct (DIR), readings are lost on power off and general (GEN), readings are stored on power off
80 reading memory for each group
zero and multi-point calibration (up to 4 points) for each group
recall or delete individually stored readings and delete group readings
statistics display for mean, minimum, maximum and deviation
definable high or low limit alarm
automatic shutdown function
USB interface for data transfer
low battery and error indicator
accuracy (induction): +/- (2.5 % + 1 µm)
accuracy (Eddy Current): +/- (2 % + 0.039 mils)
resolution: 0 µm - 99.9 µm (0.1 µm) / 100 µm - 999 µm (1 µm) / >1000 µm (0.01 mm)
minimum substrate thickness (induction): 0.2 mm
minimum substrate thickness (eddy current): 0.05 mm
minimum measuring surface: Ø 20 mm
maximum measurement rate: 2 readings per second
power supply: 2x 1.5 V battery AAA
operating humidity: 20 - 90%
units of measurement: µm, mm, mils
dimensions: 110 x 53 x 24 mm
Operating temperature    0 - 40 °C
Gross weight    605 g
Storage temperature    - 20 - 70 °C
Measuring range    0 - 2000 µm
