Automatic reel for electric cable 15 m - 3 x 1,5 mm²
Automatic reel for electric cable 15 m - 3 x 1,5 mm²
Automatic reel for electric cable 15 m - 3 x 1,5 mm² Electric cable reel 3 x 2,5mm² with PVC cable. Characteristics : Shockproof synthetic case Flexible PVC cable H05VVF with 3...

Item number

T2g-TV 27562058527

€ 418,50 *
€ 337,59 *
Quantity:
Order

Wishlist

Do you have a question about this product?

Ask us your question

Automatic reel for electric cable 15 m - 3 x 1,5 mm²
Electric cable reel 3 x 2,5mm² with PVC cable.
Characteristics :
Shockproof synthetic case
Flexible PVC cable H05VVF with 3 conductors (3 x 2,5mm²)
Rolls up and unfolds by click mechanism
With cable guide
The click mechanism can be dismantled if constant feedback is required (eg in engineering)
Swivels 180 ° left-right
CE compliant and IP42 protection class
Copper bushing, insulated up to 2.5 kV
Operating temperature from -5 to +50 ° C
Grounding with double contact
Without connecting cable and without plugs
Voltage    V    230
Maximum voltage    V    500
Cable length    m    15
Cable type        Igus CF900
Number of conductors        3G
Conductors section    mm²    2,5
Authorized power rolled    W    1900
Authorized power unrolled    W    2500
Cable diameter    mm    8,5
IP        42
Operating temperature    °C    -5 / +50
speedcontrol        Has the characteristic
Weight    kg    4,70
Dimensions (b x d x h)    mm    360x185x310
